1G Network Switch with 5 RJ45 & 1 SFP - 30W PoE+

The TL-NS5R1S-POE passes both data and electrical power to a number of PoE-compatible devices via standard twisted pair cables. Equipped with five Gigabit Ethernet ports - four of which are high-power PoE+ PSE ports - the TL-NS5R1S-POE can power wireless LAN access points and bridges, VoIP phones, IP video cameras and more while delivering network speeds of up to 1000 Mbps.

The TL-NS5R1S-POE supports the IEEE 802.3at protocol and can inject up to 30 watts of power per port. IEEE802.3af- or IEEE802.3at-compliant devices attached to the switch require no additional power. Any mix of PoE and non-PoE devices is supported, and thanks to its short circuit, overload and high-voltage protection function, your equipment is well-protected.

The TL-NS5R1S-POE is equipped with one Gigabit RJ45 and one SFP transceiver module slot. These Gigabit uplink ports are ideal for connecting the switch to the network's backbone, a server or, perhaps, your video recording solution (NVR).


Technical Features

  • Four 10/100/1000 Mbps IEEE 802.3at/af-compliant RJ45 PoE ports, one gigabit RJ45 port and one gigabit SFP port
  • Provides up to four PoE network devices with power and data
  • Total power budget of 91 watts
  • Power output up to 30 watts per port
  • Saves installation costs by delivering data and power over existing network cables
  • Complies with the IEEE 802.3az (Energy Efficient Ethernet EEE) specification
  • Mounting holes for wall mounting
  • Fully NDAA-compliant
